    Re-Manufactured Line Pump SY5133THB-9018C-6D

    Ask Lasest Price
    Brand Name : Sany heavy industry
    Model Number : SY5133THB-9018C-6D
    Price : Negotiable
    Payment Terms : T/T、L/C、D/A、D/P
    Supply Ability : 2pcs/month
    Delivery Time : 10 days
    • Product Details
    • Company Profile

    Re-Manufactured Line Pump SY5133THB-9018C-6D


    Sany Heavy Industry SY5133THB-9018C-6D vehicle pump parameter configuration
    Conventional parameters:
    unit typeSY5133THB-9018C-6DModel abbreviation5133
    Vehicle parameters:
    Vehicle Weight (kg)12855Overall dimension (length, width and height) (mm)9240×2470×3090
    dynamical system:
    power rating (kW)186Hydraulic oil tank volume (L)700
    Pump system parameters:
    Max Output Quantity(Low / High Pressure) (m³ / h)100/55Max Output Pressure(Low / High Pressure)(Mpa)9/18
    Theoretical pumping times (low / high pressure) (times / min)25/14Concrete cylinder cylinder diameter stroke (mm)230×1600
    bucket capacity (m³)0.6Feed height (mm)1500
    Chassis parameters:
    Chassis brandSany heavy industryChassis modelSYM1161T
    engine typeISDe180 40Engine power (kW)132
    engine displacement (L)4.5Maximum speed (km/h)90
    wheel base (mm)4700Fuel tank volume (L)300

    Re-Manufactured Line Pump SY5133THB-9018C-6D

    Re-Manufactured Line Pump SY5133THB-9018C-6D

    Product features and advantages:

    1:The diesel engine adopts world famous brands such as DEUTZ, which has strong power, energy conservation and environmental protection;The motor is selected from domestic famous brand, which is stable and reliable. The key hydraulic components such as pumps and valves use international famous brands to ensure the high stability of the hydraulic system.
    2:The electrical system adopts advanced bus control technology, high-quality industrial controller, display screen and remote controller, with higher control accuracy, better stability and higher reliability. The unique flexible reversing and reversing shock absorption system of the distribution buffer technology not only ensures the large swing torque, but also greatly reduces the swing impact, improves the service life of the swing cylinder and S tube, and makes the vehicle work more stable.
    3:The electrical system adopts advanced bus control technology, high-quality industrial controller, display screen and remote controller, with higher control accuracy, better stability and higher reliability.
    4:The unique flexible reversing and reversing shock absorption system of the distribution buffer technology not only ensures the large swing torque, but also greatly reduces the swing impact, improves the service life of the swing cylinder and S tube, and makes the vehicle work more stable.
